Enphase · Accessories
Enphase IQ System Controller 3
The Enphase IQ System Controller 3 connects the home to grid power, IQ Batteries, and solar PV with Microinverters.
- Regular price
- $2,099.00
- Sale price
- $2,099.00
- Regular price
-
$2,629.00
Questions before you buy?
Call 877-242-2792 and we’ll work it out with you. Mon–Thu 10am–5:30pm, Fri 10am–1pm EST.
The details.
The Enphase IQ System Controller 3 connects the home to grid power, IQ Batteries, and solar PV with Microinverters.
Use IQ System Controller 3 for all new installs using IQ8 Series Microinverters.
IQ System Controller 3 provides microgrid interconnection device (MID) functionality by automatically detecting and seamlessly transitioning the home energy system from grid power to backup power in the event of a grid failure. It consolidates interconnection equipment into a single enclosure and streamlines grid-independent capabilities of PV, storage by providing a consistent, pre-wired solution for residential applications.
DOES NOT support Generator Integration
- 10-year limited warranty
- Controls safe connectivity to the grid
- Automatically detects grid outages
- Provides seamless transition to backup
- Uses control cable for wired communication
- Connects to the load or service equipment side of the main load panel
- Centered mounting brackets support single-stud mounting
- Supports conduit entry from the bottom, bottom left and bottom right
- Enables backup for solar and solar + battery configurations
- Includes neutral-forming transformer for split phase 120/240 V backup operation
- System Shutdown Switch to disconnect PV, battery, and generator systems
- When paired with a dedicated IQ Load Controller, homeowners have the ability to prioritize and direct power to critical loads in the event of a grid outage
- Integrates hold-down functionality to eliminate the need for hold-down kits and special breakers
- Power Control System ( PCS) feature to control solar and storage operation based on Main panel rating
- Required for Sunlight Jump Start
Technical Specifications
- Maximum overcurrent protection device: 200 A
- Maximum continuous current: 160 A
- Nominal voltage: 240 VAC
- Depth 9.7 in
- Width 19.7 in
- Height 36 in
- Weight 87 lbs
Compatability
- IQ Battery 5P
- IQ Series Microinverters*
- M Series Microinverters^
- Comms Kit 2
What's Included With Your Order?
- IQ System Controller 3
- Color Coded Pre Wired System Shutdown Switch
- Wall-mounting Bracket
- Accessory Kit
- Pre Installed 4 Pole Circuit Breaker
