Complete All-In-One Off-Grid Solar Kit - 6,000W / 120/240V / 48VDC [5.3Kwh Lithium Powerwall] + 1,860 Watts Solar & LiFePO4 Battery Bank | [HBK-6] + FREE Lifetime Customer Support

Please allow 4-6 weeks for Delivery to Your Door

Looking for a complete off-grid solar kit that's simple to setup & install, comes with lithium batteries and has the ability to hook up to solar, wind, fuel/backup generator and/or utility power? Look no further! Our HBK all-in-one, off-grid solar kits were designed with all of this in mind - Simplicity. Value. Reliability.

Wether you're looking to run your RV, off-grid home/cabin or for an emergency backup solar system at your home, the HBK-6 solar kit comes with everything you need to get off the grid in just hours!

What's Included With Your HBK-6 Solar Kit Order?

Ship from USA!
1 x All in one off grid solar inverter charger (Growatt 6KW 120/240V Split Phase)
6 x 310 Watt Mono Solar Panels - 25-Year Power Output Warranty
1 x BigBattery 48V HSKY 5.3KwH, 103AH - USA Made + 10-Year Warranty!
1 x 48V 12A Charger
2 x 10AWG DC Cable 50ft each MC4-MC4 (Black & Red)
1 x 1/0AWG SB175 Battery Cable 3ft Anderson-Lugs(3/8) (Black & Red)
2 x 15A Inline Fuse
1 x 200A Inline Fuse Kit
6 x Z Brackets Solar Panel Mounting Sets
Custom Wiring Schematic
Flat Rate $299 Shipping
Lifetime Customer Support (via Phone, Email, Live Chat)

*Our kits include just about everything you need however you'll need your own installation tools and grounding rods/wire as well as optional components like current surge limiters. We also highly recommend getting professional installation by a certified solar installer and/or master electrician.

You might be wondering - is this really all I need?

The short answer is yes. However, our HBK kits are designed with the bare minimums in mind. Just enough battery and panels to get you up and running.

Our HBK solar kits will give you reliable off-grid power in

Emergency situations
Weekend getaways to your remote property
Casual power needs in a shop or outbuilding

These kits are also great for running 240V appliances in short bursts, such as:

Well pumps
Industrial equipment
Dryers and more

It's important to note that we highly recommend adding more solar panels and more batteries to our HBK solar kits down the road as you may need more juice to make it through peak power usage and/or cloudy periods.

For a system like this, we would recommend having a minimum of 2 x 5.3kwh HSKY batteries if you're planning to use this for more than emergency backup, weekend getaways or casual power needs.

What Can This Kit Actually Power?

HBK-6 is our mid-size off grid kit that has 1 x 5.3kWh Lithium power wall, giving you 5,300 watt hours of useable battery capacity.
Plus the 2kw watts of solar panels that will be generating an additional 2kw of power per hour while the sun is shining.
If we assume there's roughly 6 good sun hours in a day in most states, the solar panels will produce around 11.5kw of power each day (or 334kw/month).

The solar panels in this kit will recharge your 1 x 5.3kwh HSKY battery in 3-4 hours of good sunlight.

We have sized these with the bare minimum in mind, meaning we base the battery size on providing 15-18 hours of consistent run time in order to get us through the night and to when the sun comes back up the next day.

Because of this, we would recommend adding a backup generator to your system. All of our HBK's have the ability to hook up to a gas generator which can then recharge your lithium battery bank, extending your power and improving your reliability.

Easily Expandable. Totally Stackable. Highly Recommended.

Easily expand the kit down the road with more solar panels, more battery AND more output as every component in our HBK kits are expandable and stackable.

The Growatt all in one inverters can handle anywhere from 4.8kw-7kw of solar panel input and you can stack these for more output and more solar.

The power wall batteries are also easily expandable and connect in parallel so you can build the ultimate system as you go!

Watch Now: Everything You Need To Know About The Complete Off-Grid Solar Kit:

What does all-in-one / off grid solar kit mean?

These are essentially "complete off grid solar systems in a box". They include:

120V / 240V AC Output Inverter (6,000W Continuous / 18,000W Surge)
AC Battery Charger (Charge batteries from grid or generator)
Solar Charger Controller (built-in so just plug your solar panels in)
Circuit breakers/temperature protection/custom charge profiles
Automatic Transfer Switch (if grid/shore power is available)
100W Stand By Consumption

It does NOT get any easier than this. No more cutting/stripping/crimping wires for hours, figuring out fuse and wire sizing. Simply purchase this solar kit and you'll be up and running within an hour or 2!

Perfect for emergency backup, off grid living, emergency backup, skoolies, vans, RV's and more!

COMPLETE OFF-GRID SOLAR POWER AND/OR HOME BACKUP:

Backed By Lifetime Support

All of our solar products are backed by lifetime customer support via phone, live chat and email. We also include all of the necessary schematics for setting up your solar kit. You'll also enjoy all of the standard manufacturer's warranties on the kits component's as well as guaranteed safe delivery of everything!

Do you offer financing options?

Yes, we offer financing options on all of our solar kits up to $10,000. For kits lthat are over $10,000, give us a call and we can work with you on some form of down payment to bring the total amount required for financing under the $10k and then financing the rest.

We also offer split payments, if you need to split the purchase on two cards, give us a call and we can set this up for you as well - 877-242-2792 or for more information how to complete the financing, follow the steps here.

Growatt 48V 6000T 6kW MPV (250V Solar Input) Split Phase 120V/240V Features:

Growatt has done it again. Whole (small) house power module, all in one. There is nothing quite like it on the market.
48V 6KW Growatt SPF 6000T MVP DVM Low Frequency Split Phase 120V & 240VAC.
Supplies a massive 50A output at 120V , 25A at 240V
USA Breaker Box compatible, L1 – N – L2 (120 – 0 – 120V)
Whole house power at 6kW
a massive 18kW surge capability
Wifi Module – Growatt Shine Link for your Iphone / Android available in our store
Grid Assist Feature bypasses the inverter in case of overload or programmable UPS function, or low battery
60A Utility/Generator Battery charger (60A x 48V = 2800W at 240V Utility supply)
Generator Dry contact start output
Generator / Utility needs to supply 240V to charge the battery
100W Stand-by consumption
Weight: 105 lbs
Dimensions: 27 × 20 × 14 in

Growatt + Solar Panel Connections:

80A (5kW) Solar MPPT Charge controller (60V to 250Vmp) – Maxiumum VOC is 250VDC, but remember the lower your panel voltage the less power the MPPT can harvest

Number of panels you can connect = 5000W / [your panel wattage] – example 5000 /345W = 16 panels , 5000 / 240W = 22 (21) panels etc

Basically 230V (To be safe) / your Solar Panel VMP voltage will give you the number of panels you can connect in series

If your Solar panels’ Vmp (Voltage at maximum power – the lower of the two numbers on your panel spec) (Not Voc) voltage is between 38.3 V and 57.5V, you can connect 4 in series with matching parallel strings to add up to the number of panels as in formula above.

If your Vmp is between 28.75V and 38.3V you can connect 6 in series with matching series strings connected in parallel to add up to the number of panels as in formula above. example: 18 x 35V panels would be connected in 6s2p

If your Vmp is between 17V and 28.75V, then 8 in series with matching series strings connected in parallel to add up to the number of panels as in formula above. example 48 x 20V panels(maybe 100W) would be in 8s6p (48 panels)

Breaker Recommendation:

AC Breaker Recommendation (double pole 240V) 8AWG, 80A (Input & Output)
PV Input DC breaker (10AWG)= Total Solar Panel Watts / Solar Panel Array Voltage x 1.25 , example 2 parallel strings of 10A output panels will be around 20A
Battery , 6000W / 48V = 125A x 1.25 = 150A DC Breaker to battery bank. (2 x 3 AWG)
Battery recommended to be no less than 250Ah (12kWH, can be Lead Acid, AGM, LifePO4, Li-Ion etc any battery between 40 to 60V DC).

Battery is required to operate Growatt MPV 6000

There is no maximum battery size recommendation, we do recommend a minimum of 10-12kwh but this kit is great if you're running low watt stuff or plan on adding a 2nd battery down the line.

Growatt MPV 6000W 120/240 User manual - Click Here
Guide to programmable parameters (page 12) - Click Here

Utility/Generator Charger tips:

The generator charger is a different beast to the solar charger. (Does not utilize the Bulk and Float Charge settings). It works on a float valve type principle. (triggers when battery voltage drops below that on setting 12 – set the voltage higher than current battery voltage to start charging right away). Stops charging from Generator when setting 13′ s voltage is reached. Will not start charging the battery again until it drops below battery voltage – in setting 12.

Setting 01 set to SBU to activate setting 12 and 13. Setting 02, is the Max charging current from Solar + Utility/Generator. Setting 11, is the Maximum Generator/Utility charging current @ your battery voltage (not at 120V). Setting 14, make sure this setting includes the option to charge from utility/generator (see manual).

Note, setting Setting 11 too high for your generator may cause your generator to falter at startup, and cause the Inverter Charger to lose synchronization with the Generator (58 to 63Hz), if in doubt start small, and work your way up.

Auto Start Function for the Generator (optional)

Inverter Dry Contact relay output triggers according to the above settings, when battery charge is requested (Normally Open/Normally Closed Contacts) , it is a simple 2 wire system, your generator will need to be a 2 wire start system (the generator needs to start itself when circuit is closed, and stop when circuit opens) – this can be wired directly to the dry contact input on the inverter

MPP Solar Features:

The MPP Solar inverters are simplifying off-grid solar power. This is a complete solar system in a box. These units have been a staple in the off-grid solar power community for years for good reason. All you need to do is mount the box to the wall, connect your panels and your batteries and you're in business. Thats it. You have a fully functioning off-grid solar kit.

The MPP Solar Inverter is a perfect beginner friendly option for someone who wants to install a big off grid solar system, but doesn't have a ton of experience. With everything built-in to the MPP solar units - you can literally be up and running off grid within hours..

What Does Off-Grid Mean?

Great question. It means this system does not tie in with your local power grid / utility company. So there's no "selling" excess power back to the power company. Off-grid means your system operates 100% independent of the grid. Any excess power you're making during the day goes right into your 12 batteries included with the kit so that you can run your home / RV / cabin / shop / business all night long when the sun isn't shining.

Can I use grid power to charge the batteries and/or tie this system in with my on the grid home though?

The short answer is yes. Our off grid kits come with inverter/chargers, meaning you can suck power out of the batteries as well as throw juice back into the batteries via a generator OR any form of AC shore power (aka your grid tied home). When it comes to backing up your home or tying it in to your existing electrical system, you'll need to work with an electrician to get some form of transfer switch that will allow you to go back and forth between your homes grid tie power and your off grid battery backup.

The LV6548 Solar Inverter has the following features & benefits:

6.5kw / 48V pure sine wave output 120V AC
120A Mppt at max 250VOC – 2 x (60A – 4kW MPPT Charge Controllers) - 8,000W of solar panel input
120A Utility Charger (120A at 48V = 5.7kW or 48A at 120V)
Built-in Genset dry contact start/stop relay
Lithium / LiFePO4, AGM, Flooded, Silica Salt battery compatible, and more (custom parameters can be set according to any battery between 40 and 62V
Can be timed to only charge the battery via Utility power during certain hours (load shifting to charge on off-peak rates, and using the battery during peak tariffs) Very popular for our California Customers
High PV Input 250V (Voc) Open circuit)
Batteryless operation (singe unit mode only) (When using two or more, battery IS REQUIRED, due to the erratic nature of solar energy)
parallelable up to 6 units
built-in Wifi Transmitter
Built-in parallel kits
Dual PV inputs
BMS Support (Pylontech, Weco, Soltaro) – Separate BMS cable required
Timer for output and Timer for charging
Built-in LED RGB panel display to show operational mode
Supports Equalization Charge up to 62V
2-Year Warranty
LV6548 User Manual

LiFePO4 5.3KwH Powerwall Features:

All of our battery bank options are lithium (LiFePO4) and are MADE in the USA. Backed by a 10-year warranty. You can rest assured these batteries were built to LAST. They also have all the safety features.

48V HSKY LiFePO4 - Detailed Battery Specs:

Chemistry: LiFePO4 (LFP)
Configuration: 16S1P
Voltage: 48V
Ah Capacity: 103Ah
kWh Capacity: 5.3kWh
Wh Capacity: 5300Wh

Performance Specs:

Max Continuous Discharge Current: 130A
Max Continuous Power: 6700W
Max Discharge Peak Current: 350A (6 Seconds)
Voltage Range: 43 – 58.8V

Charging Specs:

Suggested Charge Voltage: 58.8V
Max Charge Current : 90A

Temperature Parameters:

Charge Temp Range (°C): 0°C – 55°C
Discharge Temp Range (°C): -30°C – 55°C
Optimal Discharge Temp. Range: 15°C – 35°C
Storage Temp: -20°C – 55°C (Max 6 Months)

Dimensions:

Weight: 100 (LBS)
Length: 10.25 (in)
Width: 9.5 (in)
Height: 21.5 (in)

Safety Features:

BMS (Battery Management System)
Over Voltage, Under Voltage, Over-Current
(Thermal Management System), Safety Fuse (300A)

Max battery Connections:

Series: N\A
Parallel: (YES) Cap x (8)

Features:

LED Display
Compact Modular Design
High Temp Operating Range
Best Power Density/Pack Size
Best Aluminum Mosfet Design
New A123 LiFePO4 Modules
High Cold-Cranking Amps (400A)

Warranty & Guarantee:

Made in the USA
10-Year Warranty!
Lifetime Customer Support (Phone, Live Chat Or Email)

Solar Panel Specs:

Enhanced External Load / Impact
Snow Load : 5,400 Pa
Wind Load : 2,400 Pa
Enhanced External Hail Impact : 30.7 m/s (speed ball)

Resistant to Harsh Weather Environments
Suitable for extreme conditions
Resistant to high salt mist and ammonia corrosion (certified by TÜV Rheinland)

Reassuring Warranty
25-year, linear power warranty
More than 97.5% nominal power during 1st year

Positive Power Tolerance
Positive tolerance up to +5 watts ensures return on investment

PID Resistance
Enhanced potential induced degradation with built-in state of the art SiNx encapsulant switches

Fire Safety
UL1703 Fire Classification : Type 1, Type 2

STC Rating	310.0 Watts
PTC Rating	TBD
Solar Cell Type	Polycrystalline
Module Efficiency	15.89%
Open Circuit Voltage (Voc)	45.4 Volts
Short Circuit Current (Isc)	8.96 Amps
Max. System Voltage	1,000 Volts
Frame Color	Anodized
Power Tolerance	-0 / +5%
Area	21.0 ft²
Length	77.56 in.
Width	38.98 in.
Height	1.58 in.
Weight	44.09 lbs.

What's Included With Your HBK-6 Solar Kit Order Again?

Ship from USA!
1 x All in one off grid solar inverter charger (Growatt 6KW 120/240V Split Phase)
6 x 310 Watt Mono Solar Panels - 25-Year Power Output Warranty
1 x BigBattery 48V HSKY 5.3KwH - USA Made + 10-Year Warranty!
2 x 10AWG DC Cable 50ft each MC4-MC4 (Black & Red)
1 x 1/0AWG SB175 Battery Cable 3ft Anderson-Lugs(3/8) (Black & Red)
2 x 15A Inline Fuse
1 x 200A Inline Fuse Kit
6 x Z Brackets Solar Panel Mounting Sets
Custom Wiring Schematic
Flat Rate $299 Shipping
Lifetime Customer Support (via Phone, Email, Live Chat)

*Our kits include just about everything you need however you'll need your own installation tools and grounding rods/wire as well as optional components like current surge limiters. We also highly recommend getting professional installation by a certified solar installer and/or master electrician.

$299 Flat-Rate Shipping & FREE Lifetime Customer Support!

Still have questions? Don't hesitate to reach out or give us a call today!
