Ruixu · Inverter/Charger
SKU: SUNON7.2
RUiXU SUNON7.2 7.2kW Off-Grid Inverter
Unlock reliable, off-grid power with the RUiXU SUNON7.2, a high-performance, single/split-phase inverter designed for residential and light commercial solar systems.
- Regular price
- $1,036.00
- Sale price
- $1,036.00
- Regular price
-
$1,511.56
Questions before you buy?
Call 877-242-2792 and we’ll work it out with you. Mon–Thu 10am–5:30pm, Fri 10am–1pm EST.
Frequently bought together
Specifications
The details.
Unlock reliable, off-grid power with the RUiXU SUNON7.2, a high-performance, single/split-phase inverter designed for residential and light commercial solar systems. With powerful 7,200W output, UL1741 certification, and advanced hybrid charging, this unit makes managing solar + grid energy seamless.
Key Features & Benefits:
-
7,200W Pure Sine Wave Output – Delivers stable 120V/240V power for all critical loads.
-
Hybrid Charging (Solar + Grid) – Supports up to 150A charging current, maximizing energy input flexibility.
-
Dual MPPT Inputs – 4,500W + 4,500W capacity with 99% MPPT efficiency for optimal solar harvesting.
-
Intelligent Time-Sharing – Schedule charge/discharge to reduce reliance on the grid and save money.
-
Scalable Power – Parallel up to 6 units for 43.2kW total capacity; supports three-phase output with 3+ units.
-
WiFi App Monitoring – Included WiFi dongle enables real-time system monitoring and control.
-
Rapid Shutdown Feature – Enhances safety for emergency responders.
-
UL1741 Certified – Tested for North American safety and grid compliance.
-
DIY-Friendly Setup – Includes communication cable, manual, and remote monitoring accessories.
-
3-Year Warranty – Backed by reliable support for long-term peace of mind.
Perfect for off-grid homes, cabins, solar backup setups, or expanding existing solar systems. Stackable, smart, and powerful—the SUNON7.2 puts control in your hands.
User Manual / Specifications:
- MODEL
- SUNON7.2
- Rated Output Power
- 7,200W
- Max. Output Power
- 10,800VA
- Rated Output Voltage
- 120/240 Vac (single-phase/split-phase)
- Load capacity of Motors
- 4 HP
- Rated Frequency
- 50/60Hz
- Output Wave
- Pure sine wave
- Switching Time
- 10ms(typical value)
- Battery Type
- Lithium-ion battery/lead-acid battery/user-defined battery
- Rated Battery Voltage
- 48V
- Voltage Range
- 40-60Vdc
- Max. Solar Charging Current
- 150A
- Max. Grid/Generator Charging Current
- 120A
- Max. Mix Charge Current
- 150A
- No. Of MPPT
- 2
- Max. Input Power
- 4,500W + 4,500W
- Max. Input Current
- 16A + 16A
- Max. Open Circuit Voltage
- 500Vdc
- MPPT Voltage Range
- 90-450Vdc
- Input Voltage Range
- 85-140Vac
- Input Frequency Range
- 50/60Hz
- Bypass Overload Current
- 50A
- MPPT Tracking Efficiency
- 99%
- Max. Efficiency
- 92%
- Parallel Capacity
- 1-6 Units(More than 2 units in parallel can form a three-phase output)
- Dimension
- 22.83*16.1*5inch(580*409*127mm)|
- Weight
- 42.771b(19.4kg)
- Noise
- <60dB
- Cooling Method
- Intelligent fan
- Protection Degree
- IP20 Indoor Only
- Temperature
- -10-55°C, >45°C Derate
- Warranty
- 3 years
- Communication
- RS485/CAN/USB/Dry Contact
- External Module (Optional)
- Wi-Fi/GPRS
- Integrated Circuit Breaker
- -
- Certificate
- FCC Part 15 ClassB/UL1741
- After overload protection is enabled, the inverter output will be restored after 3 min, and after 5 times of overload, the output will be off until the inverte s restarted. (102%125%
- An error will be reported, and the output will be turned off after 5s.
