Simpliphi  ·  Batteries

SKU: PHI-3.8-24-60

Simpliphi PHI 3.8 kWh LFP Battery, 24V

5.0 1 review

The PHI 3.8™ kWh 60 Amp deep-cycle Lithium Ferro Phosphate (LFP) battery is optimized with proprietary cell architecture, power electronics, BMS and assembly methods.

$2,229.00
$2,229.00
$2,990.79
You save $761.79
Pay over time at checkout.
Orders processed in 24–48 hours
30-day returns
Lifetime support by phone, chat & email
Full manufacturer warranty

Questions before you buy?

Call 877-242-2792 and we’ll work it out with you. Mon–Thu 10am–5:30pm, Fri 10am–1pm EST.

Trusted by 50,000+ Customers powered since 2018
Lifetime Support Phone, email or live chat, for good
Price Match Found it cheaper? Tell us
Ships from the USA Warehouses in CA, TX and NY

Frequently bought together

The details.

The PHI 3.8™ kWh 60 Amp deep-cycle Lithium Ferro Phosphate (LFP) battery is optimized with proprietary cell architecture, power electronics, BMS and assembly methods. It is modular, light- weight and scalable for installations that range from kWh to MWh. Provides power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile.

Simpliphi PHI 3.8 kWh LFP Battery, 24V Features:

  • Lithium Ferro Phosphate (LFP) The safest Lithium Ion chemistry available. No cobalt, risk of thermal runaway or fire
  • Built-in Battery Management System
  • Built-in SB50 Anderson Connector
  • Compatible with all industry standard inverters and charge controllers
  • Maintenance-free. No ventillation, cooling or thermal regulation required

Simpliphi PHI 3.8 kWh LFP Battery, 24V Specs:

  • Model: PHI 3.8kWh
  • 24 Volts DC
  • Nominal voltage: 25.6
  • Capacity: 151 Amp-hours
  • Rated Wh capacity at C/2: 3.8 kWh
  • Max. discharge current: 60 Amps for 10 minutes
  • Max. Continuous discharge current: 45 Amps
  • Depth of discharge: up to 100%
  • Cycle life: 10,000+
  • Built-in accessible 80 Amp DC breaker On/Off switch - increases safety and simplifies installations
  • 24V LFP batteries with proprietary architecture and Battery Management System (BMS)—do not require ventilation, cooling or thermal regulation
  • Compatible with all industry standard inverter/charge controllers
  • Drop in replacement for lead acid
  • LFP is the safest, most environmentally benign Lithium Ion chemistry available—no risk of thermal runaway or fire
  • No AC or toxic liquid cooling—negligible parasitic drain—long cycle life
  • Non-toxic and non-hazardous recyclable materials
  • Approved CA SGIP Advanced Energy Storage (AES) rebate program supplier
  • Meets transport safety weight requirements: Less than 35 kg including packaging
  • UN 3481, Lithium Ion battery contained in equipment, 9, II
  • UL and CE listed, UN/DOT and RoHS compliant components - UL Certified
  • Designed and built in California, USA
  • Dimensions: 13.5" x 14.0" x 8.0"
  • Weight: 78.24 lbs.
  • 10 year warranty
CHEMISTRY Lithium Ferro Phosphate (LFP)
The safest Lithium Ion chemistry available
No cobalt, risk of thermal runaway or fire
OCPD Built-in accessible 80 Amp DC breaker On/Off switch
BMS Built-in Battery Management System
COMPATIBILITY Compatible with all industry standard inverters and charge controllers
Battery bank-to-inverter output sizing must adhere to a 2:1 ratio:
battery quantity = (inverter kWAC rating ÷ inverter efficiency)
÷ battery MAX Continuous Discharge Rate in kWDC
MAINTENANCE Maintenance-free
No ventilation, cooling or thermal regulation required


Simpliphi PHI 3.8 kWh LFP Battery, 24V Technical Info:

SKU PHI-3.8-24-60
Weight 108.000000
Ah Rating 151
Battery Voltage 24
Dimensions (inchs) 13.5 x 14 x 8
Standard Warranty 10 years or 10,000 cycles @ 80% DOD
Manufacturer Simpliphi
